Toro® Dingo® 320-D Mini Skid Steer
Request more information:
The Toro® Dingo® 320-D Mini Skid Steer is a revolutionary compact utility loader designed to access and perform in confined spaces that were previously thought inaccessible.
PDF BROCHURE: 623_fe6baff2-1222-41e5-ad1d-c1016241f64a
SELL SHEET: 623_637d5b7e-2e7b-443c-b88d-d7f1aa120d5f
Toro® Dingo® 320-D Mini Skid Steer
The Toro® Dingo® 320-D Mini Skid Steer is a revolutionary compact utility loader designed to access and perform in confined spaces that were previously thought inaccessible. With its wheeled design and zero-turn capability, the 320-D combines maneuverability with efficient hydraulic power, making it the perfect choice for many tasks on hard surfaces or tight spots.
320-D Mini Features
4-PAW® Independent Four-Wheel Drive
The heart of the Dingo® 320-D’s unmatched traction and mobility lies in its 4-PAW® Independent Four-Wheel Drive system. This system powers all four wheels independently, delivering hydraulic flow and pressure where needed. The result is improved traction that doesn’t sacrifice maneuverability and fewer moving parts for reduced maintenance demands.
Unparalleled Operator Visibility
Thanks to the integrated ride-on operator platform, visibility is significantly improved on the 320-D. Operators have a clear view of the working area and attachments, enhancing safety and precision during operation. This visibility is crucial for efficient work in crowded or complex environments.
Exceptional Maneuverability
The Dingo® 320-D shines with its highly maneuverable design, featuring a short wheelbase that excels in navigating tight spaces. Where only hand labor could go before, the 320-D can now venture easily, opening up new possibilities for productivity and efficiency in previously challenging areas.
The Ideal Choice for Versatile Tasks
Whether you’re undertaking landscaping, construction, or maintenance tasks, the Dingo® 320-D Mini Skid Steer is equipped to handle various jobs. Its ability to quickly connect with a wide range of attachments makes it an invaluable tool for any project requiring flexibility, power, and precision.
Equipment is Our Product; Service is Our Business
At Luby Equipment, we pride ourselves on offering the best construction equipment backed by unparalleled service and support. The Toro Dingo® 320-D Mini Skid Steer exemplifies our commitment to providing innovative solutions that meet the needs of our customers. Explore how the 320-D can enhance your project efficiency and productivity today.
320-D Mini Specs
| Air Filter | Two-stage, heavy-duty, remote |
|---|---|
| Cooling System | Liquid Cooled |
| Displacement (cc) | 719 |
| Displacement (cu. in.) | 43.88 |
| Dump Angle | 34 degrees |
| Dump Height (cm) | 119 |
| Dump Height (inches) | 47 |
| Engine Make | Kubota |
| Engine Model | D722E3B |
| Fuel Tank (gallons) | 4 |
| Fuel Tank (liters) | 15 |
| Fuel Type | Diesel |
| Ground Clearance (cm) | 14.7 |
| Ground Clearance (inches) | 5.8 |
| Ground Speed Forward (mph) | 3 |
| Ground Speed Foward (km/h) | 4.8 |
| Ground Speed Reverse (km/h) | 4.8 |
| Ground Speed Reverse (mph) | 3 |
| Hinge Pin Height (cm) | 167.6 |
| Hinge Pin Height (inches) | 66 |
| Hydraulic Flow | 10.8 gpm high-flow hydraulic circuit, 4 gpm low-flow hydraulic circuit |
| Hydraulic Pressure | 3250 psi |
| Loader Arms | Radial |
| Manufacturer’s Gross HP Rating (HP) | 20 |
| Manufacturer’s Gross HP Rating (kW) | 14.9 |
| Max Operating Height (cm) | 231.6 |
| Max Operating Height (inches) | 91.2 |
| Oil Capacity (liters) | 3.2 |
| Oil Capacity (quarts) | 3.4 |
| Overall Height w/bucket (cm) | 157.5 |
| Overall Height w/bucket (inches) | 62 |
| Overall Length w/bucket (cm) | 208.8 |
| Overall Length w/bucket (inches) | 82.2 |
| Overall Width w/bucket (cm) | 123.7 |
| Overall Width w/bucket (inches) | 48.7 |
| Overall Width w/o bucket (cm) | 102.8 |
| Overall Width w/o bucket (inches) | 40.5 |
| Rated Operating Capacity* (kg) | 237 |
| Rated Operating Capacity* (lbs) | 524 |
| Reach – Fully Raised (cm) | 71.1 |
| Reach – Fully Raised (inches) | 28 |
| Reservoir Capacity (gallons) | 14.8 |
| Reservoir Capacity (liters) | 56 |
| RPM | 3600 |
| Tip Capacity (kg) | 475 |
| Tip Capacity (lbs) | 1048 |
| Weight (kg) | 781 |
| Weight (lbs) | 1722 |
| Wheelbase (inches) | 28 |
320-D Mini Dimensions
| Specification Category | Details |
|---|---|
| Wheelbase | 28″ (71.1 cm) |
| Ground Clearance | 5.8″ (14.7 cm) front & rear |
| Overall Dimensions (WxLxH) With Standard Tires | 40.5″ x 62″ x 48.7″ (102.8 x 157.5 x 123.7) |
| Overall Dimensions (WxLxH) With Narrow Tires | 35″ x 62″ x 48.7″ (88.9 x 157.5 x 123.7) |
| Maximum Operating Height | 91.2″ (231.6 cm) |
| Hinge Pin Height | 66″ (167.6 cm) |
| Dump Height | 47″ (119 cm) |
| Dump Angle | 34-degrees |
| Reach – Fully Raised | 28″ (71.1 cm) |
| Ground Speed | 0–3.7 mph (0–6 km/h), 0-3.0 mph (0–4.8 km/h) |
| Weight | 1,567 lbs (710.7 kg), 1,722 lbs (781.0 kg) |
| Tip Capacity | 1,030 lbs (467.2 kg), 1,048 lbs (475.3 kg) |
| Rated Operating Capacity (35% of Tip Capacity) | 515 lbs (233.6 kg), 524 lbs. (237.6 kg) |
