Takeuchi TB216H Hybrid Compact Excavator

Request more information:

The Takeuchi TB216H is a dual-power excavator that offers exceptional versatility due to its compact size and hybrid capabilities, making it perfectly suited for a wide range of applications where limited accessibility, noise reduction, and clean air requirements are essential. This makes it ideal for jobs such as plumbing, landscaping, utility installation, interior demolition, and rental applications.

PDF BROCHURE: Takeuchi TB216H Compact Excavator

Categories: Mini Excavator, Takeuchi Tags: compact, New

Description
Additional information

Takeuchi TB216H Hybrid Compact Excavator For Sale

For sale at Luby Equipment: Takeuchi TB216H Hybrid Excavator

One of the standout features of the TB216H is that its performance remains consistent whether it is operating on its diesel engine or electric motor. Additionally, the controls remain the same regardless of the operating mode, ensuring ease of use and operator efficiency.

Now available at Luby Equipment, the Takeuchi TB216H is an excellent choice for professionals looking for a compact and versatile excavator that can seamlessly transition between traditional and eco-friendly operations without sacrificing power or productivity.

TB216H Features

Engine and Electric Motor

EPA Final Tier 4 Compliant Diesel Engine: Ensures reduced environmental impact with features like engine preheat, extended life coolant, dual-element air filters, and an automatic fuel bleed system.
100% Emissions-Free Electric Motor: With a variable frequency drive, the TB216H offers an eco-friendly alternative for indoor use or in sensitive environments without sacrificing power or efficiency.

Electrical System

Multi-Informational Display: Keeps operators informed with visual indicators for engine preheat, high speed, water temperature, and fuel levels.
Versatile Function Keys: Allow easy transitions between hour/trip meter, time and alarm settings, and contrast adjustments, ensuring operational clarity and control.

Undercarriage and Frame

Adaptable Design: Features triple-flanged track rollers and a hydraulically retractable track frame, enabling the TB216H to navigate narrow spaces easily.
Two-Speed Travel and Adjustable Width Backfill Blade: Enhance the machine’s flexibility and precision in finishing work, supported by a cast iron wrap-around protective counterweight for added durability.

Hydraulic System

Advanced Hydraulics: Variable displacement piston pumps and cushioned boom and swing cylinders ensure smooth operation, while pilot-operated joystick controls provide precise handling.
Efficient Cooling and Maintenance: A hydraulic oil cooler and a steel hydraulic tank with a fluid level sight gauge facilitate optimal hydraulic performance and easy maintenance.

Working Equipment

Protected Hydraulic Hoses and Long Arm: Offer enhanced durability and extended reach, with options for a dual pin position bucket, mechanical bucket quick coupler, and central pin hydraulic thumb to cater to various job requirements.

Operator’s Station

Safety and Comfort: The TB216H features a ROPS/TOPS/FOPS four-post canopy for operator protection, with a pattern change valve (ISO or SAE) for adaptable control preferences.
Ergonomic Seating and Control: A suspension seat with fore and aft adjustments and foot-pedal-controlled auxiliary hydraulics ensures comfort and ease of use throughout long working hours.

Dual Power for Unmatched Versatility

The Takeuchi TB216H is not just any compact excavator; it’s a pioneering solution for modern construction challenges, offering the unique advantage of switching between diesel and electric power to meet the diverse needs of today’s projects. Whether operating in tight urban spaces, indoors, or in environments with strict emissions regulations, the TB216H delivers consistent performance and adaptability, making it a valuable addition to any fleet.

TB216H Specs

OPERATING PERFORMANCE
Operating Weight	4,277 lb	(1,940 kg)
Max. Bucket Breakout Force	4,250 lb	(1,928 kg)
Max. Arm Digging Force	1,843 lb	(836 kg)
Arm Length	3 ft 8.5 in	(1,130 mm)
Slew Speed	9.2 rpm
Traction Force	4,361 lb	(1,978 kg)
Ground Pressure	4.3 psi
Travel Speed – Low	1.4 mph	(2.2 km / hr)
Travel Speed – High	2.6 mph	(4.2 km / hr)
HYDRAULIC SYSTEM
Total Hydraulic Flow	13.4 gpm	(50.9 L / min)
Auxiliary Hydraulic Flow	8.9 gpm	(33.6 L / min)
Hydraulic System Pressure	3,046 psi	(21.0 Mpa)
ENGINE
Model / Make	Yanmar / 3TNV74
Displacement	60.0 cu in	(.99 L)
Max. Torque @ 1,800 rpm	38.2 ft-lb	(51.8 Nm)
Output Diesel Engine	14.9 hp 11.1 kW / 2,400 rpm
ELECTRIC MOTOR
Output Electric Motor	14.2 hp 10.6 kW / 2400 rpm
Electrical Connection	400 – 480 V/47 – 63 Hz / Fused w/ min. 32A
FLUID CAPACITIES
Engine Lubrication	4.5 qt	(4.3 L)
Cooling System	4.0 qt	(3.8 L)
Fuel Tank Capacity	5.8 gal	(22.0 L)
Hydraulic Reservoir Capacity	4.2 gal	(16.0 L)
Hydraulic System Capacity	6.5 gal	(24.5 L)

TB216H Dimensions

MACHINE DIMENSIONS
Maximum Reach	13 ft 5.0 in	(4,090 mm)
Maximum Reach at Ground Level	13 ft 2.9in	(4,035 mm)
Maximum Digging Depth	7 ft 10.0 in	(2,390 mm)
Maximum Vertical Digging Depth	6 ft 9.1 in	(2,060 mm)
Maximum Dig Height	12 ft 3.2 in	(3,740 mm)
Maximum Dumping Height	8 ft 10.5 in	(2,705 mm)
Front Swing Radius	4 ft 10.3 in	(1,480 mm)
Front Swing Radius with Boom Offset	3 ft 9.4 in	(1,155 mm)
Tail Swing (Slew) Radius	4 ft 4.6 in	(1,335 mm)
Transport Length	13 ft 6.8 in	(4,135 mm)
Transport Height	7 ft 4.8 in	(2,255 mm)
Ground Clearance	8.1 in	(205 mm)
Undercarriage Length	4 ft 11.9 in	(1,520 mm)
Track Width (Rubber)	9.0 in	(230 mm)
Undercarriage Width – Track Retracted	38.6 in	(980 mm)
Undercarriage Width – Track Extended	51.2 in	(1,300 mm)
