CASE SL12 Small Articulated Loader

Key Features:

• Compact Design:
  • Width just over 36” with appropriate tire option, allowing access to tight spaces.
  • Easily transportable, fitting into standard trailers.
• Power and Control:
  • Equipped with a 25 hp engine, delivering substantial power in a compact frame.
  • Intuitive joystick and hydraulic controls for precise operation.
  • Impressive lifting capacity of over 2,400 lbs., ideal for various applications.

Unmatched Stability and Versatility:

• Stability:
  • Unique articulation and oscillation features for superior stability and operator confidence.
• Versatility:
  • CII coupler and optional continuous flow auxiliary hydraulics.
  • Compatible with more than 70 attachments, ready for diverse job requirements.

Designed for Accessibility:

• Ease of Use:
  • Lighter and narrower design for enhanced maneuverability.
  • Engineered to simplify access to confined areas.

Operator Comfort and Safety:

Allowing for the well-being and comfort of the operator is paramount. The SL12 comes equipped with:

• ROPS/FOPS safety roof for enhanced operator protection.
• Safety entry bar that allows for safe ingress and egress.
• Convenient key start system.
• Comfortable non-suspension vinyl seat with armrests for extended operation periods.
• Retractable seat belt for added safety.
• Exterior mirrors for improved visibility and safety.

Robust and Reliable Engine:

The heart of the SL12 is its robust engine, designed to deliver consistent performance with:

• Glow plug starting aid for reliable starts in cold weather.
• Engine block heater for enhanced performance in low temperatures.
• Locking fuel cap to secure your fuel.

Advanced Drivetrain:

The SL12’s drivetrain is built for precision and ease of use, featuring:

• Hydrostatic 4-wheel drive for superior traction and control.
• FNR (Forward-Neutral-Reverse) control is integrated into the joystick for smooth operation.
• Electro-hydraulic controlled manually activated differential lock for optimal power distribution.
• Hydraulic parking brake for secure stopping and parking.

Efficient Hydraulics:

The hydraulic system of the SL12 is designed for versatility and power, equipped with:

• 3-spool main control valve to handle multiple functions simultaneously.
• 1x dual-acting auxiliary hydraulics for a wide range of attachments.
• Attachment case drain return to prevent hydraulic fluid overflow.
• Loader’s arm float function allows the bucket to follow the ground’s contour.
• Oil cooler to maintain optimal hydraulic fluid temperatures.

Loader Specifications:

The loader unit of the SL12 is built for heavy-duty tasks, featuring:

• A standard lift path is used for straightforward lifting and loading.
• Mechanical self-leveling to keep loads stable and secure.
• Loader lifts arm support struts for safe maintenance and service.
• CII mechanical attachment coupler for easy attachment changes.
• Additional counterweights for improved stability and lifting capacity.

Electrical and Lighting:

The SL12’s electrical system ensures reliability and convenience with:

• 12-volt system to power all electrical components.
• 52 AHR, 520 CCA battery for reliable power.
• 40 A alternator to keep the battery charged and the electrical system running.
• Two front cab work lights for enhanced visibility during early morning or nighttime operations.
• Remote jumpstart provision for emergency power needs.

Other Standard Features:

The SL12 is also equipped with additional features to enhance its utility and safety, including:

• Recovery hook for towing or rescue operations.
• Lifting eyes for easy transportation and lifting.
• Backup alarm to alert nearby personnel when reversing.
• Horn for signaling and safety communication.

Engine Customization:

• Hand Throttle: Provides manual control over the engine speed, allowing for precise adjustments to suit different tasks and conditions.

Drivetrain Enhancements:

• Hand Inching Creep Control: The operator can finely control the machine’s speed at low levels, ideal for tasks requiring precision and care.

Hydraulic System Upgrades:

• 2x Dual Acting Auxiliary Hydraulics: Doubles the hydraulic capability, enabling the use of more complex attachments that require additional hydraulic functions.
• Auxiliary Hydraulic Hold Function: Allows continuous hydraulic pressure to be maintained to an attachment, essential for tools requiring a constant flow.
• Continuous-Flow Auxiliary Hydraulics: Allows for a steady flow of hydraulic fluid, perfect for attachments that need continuous operation, such as sweepers or snow blowers.

Electrical Options:

• Additional Worklights: Enhance visibility with an extra boom worklight and two additional cab rear work lights, ensuring safe and efficient operation in low-light conditions.
• 3-Pin Electrical Auxiliary Connection: Provides a convenient power source for electrical attachments, expanding the range of compatible tools.
• Rotating Beacon Light: Increases visibility and safety on busy sites or low-visibility conditions, alerting others to the loader’s presence.

Other Customizable Features:

• Operator Manual in Multiple Languages: Choose from English, Spanish, or French for the operator manual, ensuring clear understanding and safe operation for diverse teams.
• Groundskeeper Tool Carrying Kit: A specialized kit designed for landscaping and grounds maintenance tasks, providing easy transport and access to essential tools.

• Base warranty coverage: 2-Year/1,000-Hour
• Full Machine Limited Warranty
• Electric power train warranty coverage: 3-year/3,000 Hour Limited Warranty (EV models only)
