Fecon Bullhog 150-200 HP Tractor Head Attachment
Request more information:
The Fecon Bullhog 150-200 HP Tractor Head Attachment, designed for purpose-built forestry tractors, excels in clearing brush, trees, and stumps to ground level. Engineered for efficiency, it swiftly mulches standing trees and processes trees up to 8-10 inches in diameter, making it an indispensable tool for comprehensive land management and forestry tasks.
Brochure: Fecon Bullhog 150-200 HP Tractor Head Attachment Brochure
Fecon Bullhog 150-200 HP Tractor Head Attachment
The Fecon Bullhog 150-200 HP Tractor Head Attachment, designed for purpose-built forestry tractors, excels in clearing brush, trees, and stumps to ground level. Engineered for efficiency, it swiftly mulches standing trees and processes trees up to 8-10 inches in diameter, making it an indispensable tool for comprehensive land management and forestry tasks.
Bullhog 150-200 HP Features
Unmatched Durability
- Severe-Duty Body Construction: This industry-leading robust construction is designed for extreme demands, ensuring reliability and longevity even with full-time, intensive use over thousands of hours.
Versatile Cutting Options
- Two Rotor Systems: This system accommodates a variety of cutting tools, including Double Carbide, High Abrasion, Stone Tool, Viking Sword, and Viking Axe, allowing for customization based on project needs.
Optimized Performance
- Variable Speed Motor: Fecon’s innovative motor adjusts the Bull Hog’s motor displacement automatically, optimizing rotor speed and torque according to the load of the material being processed.
- Lighter Material Loads: Increases RPM for finer Bull Hog sizing and more efficient mulching.
- Heavier Material Loads: Boosts rotor torque to prevent stalling, ensuring continuous operation even in demanding conditions.
Enhanced Control and Finishing
- Adjustable Pin-On Push Bar: Features serrated ears for improved material direction and mulching efficiency.
- Curved Skid Shoes: Made from wear-resistant AR400 steel, these adjustable skid shoes minimize material plowing and promote uniform results.
- Bull Hog Trap Door: Aids in debris containment and achieves finer material sizing for a polished finish.
Compatibility and Mounting
- Mounting Options: Standard pin-on and quick-attach mounts cater to a wide range of prime movers, with custom mounts available upon request to ensure compatibility with various machinery.
Bullhog 150-200 HP BH74SD Specs
| MODEL | BH74SD – 1 | BH74SD – 2 |
|---|---|---|
| WORKING WIDTH | 61″ / 1549mm | 61″ / 1549mm |
| OVERALL WIDTH | 76″ /1930mm | 76″ /1930mm |
| WEIGHT (LBS/KG) | 2750lbs / 1247kg | 2800lbs / 1270kg |
| FLOW RANGE (GPM) | 27 – 50 | 40 – 75 |
| FLOW RANGE (LPH) | 102 – 190 | 151 – 284 |
| MAX PRESSURE (PSI) | 6000 | 6000 |
| TOOLS PER STANDARD ROTOR | 30 | 30 |
| TOOLS PER DCR ROTOR | 24 | 24 |
| ROTOR DIAMETER | 20″ / 500mm | 20″ / 500mm |
| ROTOR SPEED (RPM) | 2000 | 2000 |
| ROTOR BEARING SIZE (MM) | SD65 | SD65 |
| MOTOR(S) | 1 x 107V | 1 x 160V |
Bullhog 150-200 HP BH85SD Specs
| MODEL | BH85SD – 1 | BH85SD – 2 |
|---|---|---|
| WORKING WIDTH | 72″ / 1829mm | 72″ / 1829mm |
| OVERALL WIDTH | 87″ / 2210mm | 87″ / 2210mm |
| WEIGHT (LBS/KG) | 2970lbs / 1347kg | 3050lbs / 1383kg |
| FLOW RANGE (GPM) | 27 – 50 | 40 – 75 |
| FLOW RANGE (LPH) | 102 – 190 | 151 – 284 |
| MAX PRESSURE (PSI) | 6000 | 6000 |
| TOOLS PER STANDARD ROTOR | 36 | 36 |
| TOOLS PER DCR ROTOR | 28 | 28 |
| ROTOR DIAMETER | 20″ / 500mm | 20″ / 500mm |
| ROTOR SPEED (RPM) | 2000 | 2000 |
| ROTOR BEARING SIZE (MM) | SD65 | SD65 |
| MOTOR(S) | 1 x 107V | 1 x 160V |
Bullhog 150-200 HP Warranty
FECON STANDARD WARRANTY 12 MONTHS / 1,000 HRS
