CASE 750M Dozer
Request more information:
The CASE 750M packs 20,000 lbs. of dirt-driving versatility into a compact yet powerful package. This dozer excels in both finish grading and more demanding earthwork with a best-in-class 41,000 lbs. of drawbar pull. Its robust undercarriage design not only extends track life but also significantly reduces vibration, enhancing operator comfort and machine durability.
Horsepower: 96 hp | Operating Weight: 20,228 lb
BROCHURE: CASE M Series Dozers
SPEC SHEET: CASE 750M Dozer
CASE 750M Dozer For Sale
For sale at Luby Equipment: CASE 750M Dozer
Horsepower: 96 hp | Operating Weight: 20,228 lb
The CASE 750M packs 20,000 lbs. of dirt-driving versatility into a compact yet powerful package. This dozer excels in both finish grading and more demanding earthwork with a best-in-class 41,000 lbs. of drawbar pull. Its robust undercarriage design not only extends track life but also significantly reduces vibration, enhancing operator comfort and machine durability.
Featuring an advanced load management system, the 750M adjusts track speed according to the size of the load—slowing down for larger loads and speeding up for lighter ones, ensuring efficient operation regardless of the task at hand. The spacious cab provides ample room, offering a comfortable work environment for long hours on the job.
Operation is made easy with the new EH blade control joystick, providing precision and ease of use that makes it a favorite among operators. Now available at Luby Equipment, the CASE 750M dozer is a versatile powerhouse, perfect for a wide range of tasks from grading to intensive earthmoving, delivering performance that gets the job done.
750M Features
New Blade Control Update & Product Enhancements:
- Enhanced Ergonomics: Updated electro-hydraulic blade controls improve ergonomics, reducing operator fatigue with an ergonomic joystick featuring blade shake and fine-grade buttons.
- Streamlined Configuration: The new design simplifies the setup for machine control systems by eliminating the need for an additional EH valve, enhancing both cost-efficiency and serviceability.
- Durability and Visibility: Redesigned electrical routings and hydraulic systems extend the machine’s reliability, while premium LED lights and a new rear-view camera ensure optimal visibility and safety.
Power and Productivity:
- Unmatched Capability: With best-in-class horsepower and drawbar pull, the 750M ensures exceptional performance and tractive effort for any task.
- Control Customization: Operators can tailor shuttle and steering sensitivity to match site conditions, while an advanced load monitoring system optimizes power and efficiency according to the blade’s load.
Operator Comfort and Jobsite Visibility:
- Superior Sight Lines: Offers industry-leading visibility to the blade, tracks, and worksite, complemented by a spacious, positive-pressure cab designed to keep out dirt, dust, and noise.
- Smooth Operation: The isolated cab design minimizes vibration, ensuring a comfortable and smooth ride.
Ease of Maintenance and Service:
- Convenient Serviceability: Grouped service points and easy access, combined with the enhanced CASE SiteWatch™ telematics, provide valuable insights into machine performance and maintenance needs, promoting optimal uptime.
Protected by CASE ProCare:
- Comprehensive Coverage: Enjoy peace of mind with a three-year, 3,000-hour full-machine factory warranty, a three-year, 2,000-hour planned maintenance contract, and a three-year advanced CASE SiteWatch™ telematics subscription.
750M Standard Equipment
Operator Environment:
- ROPS Canopy: Isolation-mounted for reduced vibration, with an optional ROPS cab for enhanced protection.
- Control: Single lever control integrates speed, steering, and direction for simplified operation.
- Seating: Vinyl mechanical suspension seat with tilt access and optional cloth air suspension seat featuring adjustable armrests for maximum comfort.
- Visibility and Convenience: Includes a rear view and additional mirrors, a dome light, two-door windshield wipers, a rear wiper, and a 12-volt accessory outlet.
- Communications: Bluetooth radio for connectivity alongside warning lights and gauges for comprehensive machine status monitoring.
Engine:
- Powerplant: The FPT F5HFL413J*A002 engine, Tier 4 Final certified, combines CEGR and DPF technologies for environmental compliance.
- Cold Start Aid: Glow plugs ensure reliability in cold conditions, supported by an automatic fan belt tensioner and integral engine oil cooling.
Drivetrain:
- Hydrostatic Drive: Offers dual path, infinitely variable control with electronic straight tracking, power turns, and counter-rotation.
- Final Drive: Features triple reduction with a helical gear/planetary decelerator for robust power delivery.
Blade:
- Versatility: 52° – 60° variable pitch blade, with single lever electro-hydraulic control for precise manipulation.
Undercarriage:
- Durability: Hydraulic track adjusters, sealed and lubricated track chain (SALT), and heavy-duty components ensure long-term reliability and performance.
Safety and Utility:
- Lighting: Premium LED work light package enhances visibility, while the backup alarm and horn ensure safety on the job site.
- Accessibility: Hinged engine side panels, a master disconnect switch, and diagnostic check ports facilitate maintenance and troubleshooting.
Telematics and ProCare:
- SiteWatch™ Telematics: A 5-year advanced data subscription provides insightful machine performance monitoring.
- ProCare Protection: Includes a full machine protection factory warranty, planned maintenance, and telematics support for peace of mind and controlled operating expenses.
750M Optional Equipment
Rear Mounted Equipment:
- Ripper: Equipped with five positions and three shanks, enhancing the dozer’s capability in challenging ripping applications.
- Hydraulic Pump with PTO: Offers added versatility for using various attachments.
- Drawbar: Provides added functionality for towing and pulling tasks on the jobsite.
Blade Options:
- Blade Sizes: To match your specific job requirements, choose from 96 in (2.44 m) LT, 108 in (2.73 m) LT/WT/LGP, or 124 in (3.16 m) WT/LGP blades.
- Precision: Elevate your grading precision with options like Factory Fit CoPilot, 2D Laser, and 3D GNSS systems alongside Universal Blade Guidance Ready for advanced control and accuracy.
Screens for Added Protection:
- Radiator Brush Screen: Protects the radiator from debris, enhancing the machine’s durability.
- ROPS Side Screen and Rear: Offers additional protection for the operator and the cab in environments with potential falling debris.
Other Enhancements:
- Case Max-Life Track: Provides extended undercarriage life in harsh conditions.
- Front Counterweight: Improves machine balance and stability when handling heavy loads.
- Severe Cold Weather Package: Allows for reliable operation in extremely cold conditions, featuring enhancements like a rear-view camera designed for cab models.
Precision Control Systems:
- Factory Fit Solutions: Optimize your dozer for precision work with CoPilot, 2D Laser, and 3D GNSS systems, which provide the tools for efficient and accurate grading and site preparation.
Operator and Machine Protection:
- Cold Weather and Camera Options: Ensure smooth operation in cold environments and enhance jobsite awareness with the rear-view camera, a crucial feature for safety in crowded or limited visibility conditions.
750M Specs
| Engine Specification | Detail |
|---|---|
| Model | FPT F5HFL413J*A002 |
| Emissions Certification | Tier 4 Final Certified |
| Cylinders | 4 |
| Displacement | 207.5 in³ (3.4 L) |
| Fuel Injection | Common rail |
| Fuel Type | #2 Diesel |
| Fuel Filter | Spin-on with in-line strainer |
| Air Intake | Cross-flow |
| Cooling | Liquid |
| Engine Speeds (RPM) | High idle – no load: 2200 +/- 50, Rated – full load: 2200, Low idle: 1100 +/- 25 |
| Horsepower @ 2000 RPM – SAE J1349 | Net: 92 hp (69 kW), Gross: 96 hp (72 kW) |
| Engine Lubrication | Deep sump plate cooler with pressurized under-piston nozzles |
| Pump Operating Angle Ratings | Side-to-side: 35°, Fore and aft: 45° |
| Oil Filtration | Replaceable, spin-on full-flow cartridge |
| Radiator Fins Per Inch | 10.16 |
| Fan Diameter | 26.0 in (662 mm) |
| Fan Ratio | 1.1:1 |
750M Dimensions
| Dimension | Long Track (LT) | Wide Track (WT) | Low Ground Pressure (LGP) |
|---|---|---|---|
| Blade Width | 96 in (2,438 mm) | 108 in (2,731 mm) | 124 in (3,160 mm) |
| SAE Blade Capacity | 1.69 yd³ (1.29 m³) | 1.89 yd³ (1.44 m³) | 2.22 yd³ (1.70 m³) |
| A. Blade Height | 33.1 in (841 mm) | 33.1 in (841 mm) | 33.1 in (841 mm) |
| B. Blade Lift Above Ground | 33.85 in (860 mm) | 33.85 in (860 mm) | 33.85 in (860 mm) |
| C. Blade Depth Below Ground | 22.84 in (580 mm) | 22.84 in (580 mm) | 22.84 in (580 mm) |
| Blade Angle Both Directions | 22.7° | 22.7° | 22.7° |
| D. Cast Reach | 9.11 in (231.3 mm) | 10.4 in (214.3 mm) | 14.3 in (362.3 mm) |
| E. Cut Reach | -2.63 in (-66.8 mm) | -3.3 in (-84.1 mm) | 2.5 in (64.2 mm) |
| Blade Tilt, Each End (+/- 9°) | 7.64 in (194 mm) | 8.54 in (217 mm) | 9.86 in (250 mm) |
| Track Gauge | 62 in (1.57 m) | 70 in (1.78 m) | 70 in (1.78 m) |
| Maximum Shoe Width | 20 in (508 mm) | 24 in (610 mm) | 28 in (711 mm) |
| F. Length of Track on Ground | 89.2 in (2.26 m) | 89.2 in (2.26 m) | 89.2 in (2.26 m) |
| Area of Track on Ground | 3,606 in² (2.3 m²) | 4,330 in² (2.8 m²) | 5,047 in² (3.3 m²) |
| Ground Pressure | 5.36 psi (0.37 bar) | 4.61 psi (0.32 bar) | 4.04 psi (0.28 bar) |
| G. Height to Top of ROPS Canopy | 9 ft 1 in (2,755 mm) | 9 ft 1 in (2,755 mm) | 9 ft 1 in (2,755 mm) |
| H. Ground Clearance | 14.0 in (355 mm) | 14.0 in (355 mm) | 14.0 in (355 mm) |
| Length (Blade Straight with Drawbar) | 14 ft 1 in (4,284 mm) | 14 ft 1 in (4,284 mm) | 14 ft 1 in (4,284 mm) |
| I. Blade Straight with Ripper | 16 ft 9 in (5,110 mm) | 16 ft 9 in (5,110 mm) | 16 ft 9 in (5,110 mm) |
| Width (J. Blade Straight) | 8 ft 0 in (2,438 mm) | 9 ft 0 in (2,731 mm) | 10 ft 4 in (3,160 mm) |
| Blade Angled (Transport Width) | 7 ft 7 in (2,316 mm) | 8 ft 6.4 in (2,602 mm) | 9 ft 9 in (2,965 mm) |
| K. Over Track | 6 ft 7 in (2,018 mm) | 7 ft 7 in (2,304 mm) | 8 ft 2 in (2,488 mm) |
Warranty
Base & Extended Warranty Coverage
CASE ProCare applicable on select new heavy machine orders
See your CASE dealer for model availability and timing
Additional information
| Condition | New |
|---|
